Domestic Network Application Platform
NPC-8208B-HG is a standard 2U rack mount domestic network security application product developed based on the domestic Hygon 3200 series processor, supporting 4 × DDR4 memory slot. The capacity of the complete PC can reach 128G, with onboard 2 × Gigabit LAN port and 4 × ENS networkr module (optional 8 × ENS extension slots). The complete PC supports up to 34 × Gigabit LAN port (optional 16 groups of bypass). NPC-8208B-HG can be widely used in the network security fields of finance, power, telecommunications, energy, transportation, medical and other industries, such as firewalls, antivirus walls, load balancing, Internet behavior management and audit, application delivery, WAF, IDS/IPS, UTM and other network security application scenarios.
Item | Description | |
---|---|---|
系统配置 | 处理器 | 支持Hygon-3250、3330、3350等处理器 |
芯片组 | HG-3系 SOC | |
内存 | 4个DDR4内存插槽,整机总容量可达256G,默认配1条8GB内存 | |
存储器 | SATA | 3个SATA3.0接口,标配1个硬盘位(空闲2个SATA3.0接口) |
IO接口 | USB | 2个USB3.0接口(前置接口),2个USB3.0插针(内置) |
COM | 1个RJ45形式Console口(前置接口),1个RS232串口插针(内置) | |
GPIO | 支持8路数字GPIO | |
显示接口 | 1个VGA接口 | |
网口 | 网卡芯片 | Intel® i211/I210 |
网口类型 | 板载2个千兆电口 | |
扩展总线 | PCIE | 1个PCIE3.0 x4槽(选配,X4信号),可选模块1090-014911 EB-X4N-100B |
ENS | 标配4个ENS网卡扩展槽位,最大可扩展8个ENS网卡扩展槽位 | |
搭配主板 | NET-1838VD2N系列 | |
工作环境 | 温度:0℃~40℃ 湿度:10%~ 90%(非凝状态) |
|
储存环境 | 温度:-20℃-70℃ 湿度:10%-90%(非凝结状态) |
|
产品尺寸 | 440mm(W)*88mm(H)*550mm(D) | |
电源 | 350W ATX 冗余电源 | |
操作系统 | 银河麒麟,中标麒麟、麒麟信安等海光版操作系统,详细请查阅产品说明书 |
料号 | 型号 | 描述 |
---|---|---|
0010-204631 | NPC-8208B-HG03/3250YH/8G/1T/8ENS/350W redundant power supply | Hygon Platform HG3250 eight-core 16-thread 2.8GHz/1*8GB DDR4/1*1TB 3.5"HDD/onboard 2*Gigabit electrical ports/8*ENS slot/1*VGA port/1*350W redundant power supply/2U network rack mount system |
0010-200361 | NPC-8208B-HG04/3330/8G/1T/4ENS/350W redundant power supply | Hygon Platform HG3330 quad-core 8-thread 3.0GHz/1*8GB DDR4/1*1TB 3.5"HDD/onboard 2*Gigabit electrical ports/4*ENS slot/1*VGA port/1*350W redundant power supply/2U network rack mount system |
0010-200371 | NPC-8208B-HG05/3350/8G/1T/4ENS/350W redundant power supply | Hygon Platform HG3350 eight-core 16-thread 3.0GHz/1*8GB/1*1TB 3.5"HDD/onboard 2*Gigabit electrical ports/4*ENS slot/1*VGA port/1*350W redundant power supply/2U network rack mount system |
